Boreal North America Europe Global - Land Middle East Temperate North America

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Interannual Variability Score [1]	Overall Score [1]
Benchmark	[-]	274.
bcc-csm1-1	[-]	314.		7.24	22.5	0.00		0.434	0.668	1.00	0.431	0.641
bcc-csm1-1-m	[-]	317.		13.9	27.6	0.00		0.382	0.636	1.00	0.404	0.611
CESM1-BGC	[-]	316.		8.45	24.3	0.00		0.424	0.651	1.00	0.431	0.631
E3SMv1-CTC	[-]	309.		7.17	23.8	0.00		0.435	0.649	1.00	0.411	0.629
E3SMv1-ECA	[-]	307.		3.74	23.0	0.00		0.465	0.649	1.00	0.420	0.636
GFDL-ESM2G	[-]	304.		-7.92	20.3	1.03		0.429	0.688	0.930	0.457	0.639
inmcm4	[-]	311.		5.69	25.1	1.02		0.448	0.627	0.933	0.438	0.614
IPSL-CM5A-LR	[-]	312.		11.0	23.6	1.03		0.404	0.683	0.930	0.429	0.626
MeanCMIP5	[-]	310.		3.53	16.0	0.00		0.467	0.744	1.00	0.425	0.676
MIROC-ESM	[-]	320.		6.42	26.4	1.03		0.441	0.611	0.930	0.416	0.602
MPI-ESM-LR	[-]	304.		-4.87	21.4	2.05		0.455	0.662	0.745	0.423	0.589
NorESM1-ME	[-]	305.		-6.87	19.1	1.03		0.438	0.704	0.930	0.465	0.648

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Interannual Variability Score [1]	Overall Score [1]
Benchmark	[-]	361.
bcc-csm1-1	[-]	365.		5.39	18.5	0.00		0.0961	0.620	1.00	0.463	0.560
bcc-csm1-1-m	[-]	364.		-4.96	18.2	0.00		0.0972	0.621	1.00	0.291	0.526
CESM1-BGC	[-]	371.		-14.3	21.0	1.03		0.0756	0.659	0.930	0.403	0.545
E3SMv1-CTC	[-]	358.		-11.8	21.5	1.03		0.0808	0.619	0.930	0.293	0.509
E3SMv1-ECA	[-]	356.		-12.6	21.0	0.00		0.0791	0.637	1.00	0.446	0.560
GFDL-ESM2G	[-]	367.		-3.86	18.8	0.00		0.100	0.609	1.00	0.395	0.543
inmcm4	[-]	364.		-7.45	18.7	0.00		0.0909	0.632	1.00	0.301	0.531
IPSL-CM5A-LR	[-]	357.		-20.8	26.6	0.00		0.0634	0.647	1.00	0.333	0.538
MeanCMIP5	[-]	366.		-3.46	14.7	0.00		0.101	0.681	1.00	0.413	0.575
MIROC-ESM	[-]	374.		8.87	17.3	0.00		0.0875	0.666	1.00	0.420	0.568
MPI-ESM-LR	[-]	367.		-9.19	18.9	0.00		0.0867	0.641	1.00	0.398	0.554
NorESM1-ME	[-]	368.		-2.24	17.6	0.00		0.105	0.626	1.00	0.384	0.548

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Interannual Variability Score [1]	Overall Score [1]
Benchmark	[-]	366.
bcc-csm1-1	[-]	371.		-5.26	25.9	0.00		0.230	0.641	1.00	0.475	0.597
bcc-csm1-1-m	[-]	375.		3.49	31.4	0.00		0.205	0.643	1.00	0.367	0.571
CESM1-BGC	[-]	371.		-3.44	24.2	0.397		0.216	0.655	0.973	0.467	0.593
E3SMv1-CTC	[-]	365.		-11.7	28.1	0.795		0.207	0.655	0.947	0.416	0.576
E3SMv1-ECA	[-]	364.		-12.9	28.8	0.556		0.211	0.647	0.963	0.405	0.574
GFDL-ESM2G	[-]	370.		-7.50	28.1	0.159		0.214	0.645	0.989	0.439	0.586
inmcm4	[-]	362.		-12.5	31.4	0.313		0.197	0.699	0.979	0.382	0.591
IPSL-CM5A-LR	[-]	364.		-13.1	29.2	0.0795		0.199	0.658	0.995	0.424	0.587
MeanCMIP5	[-]	369.		-6.59	22.5	0.00		0.226	0.716	1.00	0.493	0.630
MIROC-ESM	[-]	373.		-2.84	26.2	0.159		0.211	0.660	0.989	0.461	0.596
MPI-ESM-LR	[-]	371.		-2.18	24.7	0.472		0.219	0.721	0.959	0.508	0.626
NorESM1-ME	[-]	367.		-12.6	21.1	0.238		0.220	0.686	0.984	0.541	0.624

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Interannual Variability Score [1]	Overall Score [1]
Benchmark	[-]	457.
bcc-csm1-1	[-]	443.		4.88	12.8	0.00		0.302	0.805	1.00	0.465	0.675
bcc-csm1-1-m	[-]	446.		3.63	14.4	0.00		0.310	0.762	1.00	0.287	0.624
CESM1-BGC	[-]	439.		-9.45	12.4	0.00		0.276	0.796	1.00	0.310	0.635
E3SMv1-CTC	[-]	429.		-20.1	24.0	0.00		0.223	0.787	1.00	0.333	0.626
E3SMv1-ECA	[-]	429.		-20.0	23.1	0.00		0.223	0.771	1.00	0.333	0.620
GFDL-ESM2G	[-]	446.		-6.87	16.6	0.00		0.291	0.724	1.00	0.286	0.605
inmcm4	[-]	408.		-41.1	43.2	0.00		0.147	0.733	1.00	0.293	0.581
IPSL-CM5A-LR	[-]	430.		-26.8	28.7	0.00		0.195	0.791	1.00	0.472	0.650
MeanCMIP5	[-]	439.		-9.21	11.7	0.00		0.277	0.836	1.00	0.310	0.652
MIROC-ESM	[-]	438.		-2.79	13.5	0.00		0.315	0.767	1.00	0.446	0.659
MPI-ESM-LR	[-]	438.		-1.96	9.43	0.00		0.321	0.826	1.00	0.303	0.655
NorESM1-ME	[-]	436.		-8.81	12.3	0.00		0.280	0.823	1.00	0.308	0.647

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Interannual Variability Score [1]	Overall Score [1]
Benchmark	[-]	380.
bcc-csm1-1	[-]	374.		-10.0	24.8	0.00		0.681	0.693	1.00	0.703	0.754
bcc-csm1-1-m	[-]	384.		-1.41	30.1	0.00		0.606	0.632	1.00	0.637	0.702
CESM1-BGC	[-]	384.		-2.64	22.9	0.459		0.650	0.712	0.969	0.814	0.772
E3SMv1-CTC	[-]	372.		-15.1	25.8	1.03		0.624	0.718	0.930	0.812	0.760
E3SMv1-ECA	[-]	370.		-16.3	27.1	0.804		0.634	0.705	0.946	0.820	0.762
GFDL-ESM2G	[-]	369.		-14.7	24.1	0.115		0.636	0.706	0.992	0.765	0.761
inmcm4	[-]	371.		-17.6	28.3	0.230		0.608	0.710	0.985	0.766	0.756
IPSL-CM5A-LR	[-]	372.		-16.4	27.3	0.00		0.618	0.714	1.00	0.780	0.765
MeanCMIP5	[-]	376.		-10.7	21.0	0.00		0.660	0.784	1.00	0.823	0.810
MIROC-ESM	[-]	382.		-4.47	25.3	0.115		0.606	0.726	0.992	0.803	0.771
MPI-ESM-LR	[-]	382.		-6.44	22.9	0.344		0.653	0.725	0.977	0.811	0.778
NorESM1-ME	[-]	373.		-14.6	22.0	0.115		0.639	0.752	0.992	0.875	0.802

Australia Boreal Asia Boreal North America Central America Central Asia Equatorial Asia Europe Global - Land Middle East Northern Hemisphere Africa Northern Hemisphere South America Southeast Asia Southern Hemisphere Africa Southern Hemisphere South America Temperate North America Temporally integrated period mean Temporally integrated period mean bias Temporally integrated period mean bias score Temporally integrated period mean max month Temporally integrated mean phase shift Temporally integrated mean phase shift score Temporally integrated period mean rmse Temporally integrated period mean rmse score Interannual variability Interannual variability score Spatially integrated regional mean cycle Spatially integrated regional mean detrended cycle Spatially integrated regional mean

  Title:

derived WRMC BSRN

  Source_file:

This product is generated from monthly WRMC.BSRN observations

  Conventions:

Please contact Prof. James Randerson (Email: jranders@uci.edu) or Dr. Mingquan Mu (mmu@uci.edu) for any question

  Altitude:

BSRN

  Site_name:

ASP,BAR,BER,BIL,BON,BOS,BOU,BRB,CAB,CAM,CAR,CLH,CNR,COC,DAA,DAR,DOM,DRA,DWN,E13,EUR,FLO,FPE,FUA,GCR,GVN,ILO,ISH,IZA,KWA,LAU,LER,LIN,MAN,MNM,NAU,NYA,PAL,PAY,PSU,PTR,REG,RLM,SAP,SBO,SMS,SOV,SPO,SXF,SYO,TAM,TAT,TIK,TOR,XIA

  Creation_date:

Sun Jun 22 23:45:11 PDT 2014

  Approach:

First I used BSRN Toolbox to extract lwup (surface upward longwave radiation) from raw data files, and saved the data in ascii format, then I organized all site data together for each month and year and saved them in a netcdf file.

  Temporal resolution:

monthly

  General information:

This product was derived from WRMC-BSRN radiation dataset.

  Spatial resolution:

site observations

  Derived data code:

http://redwood.ess.uci.edu/mingquan/www/ILAMB/Download/CODES/CODES/subroutines/convert/convert-WRMC.BSRN.ncl
